JEV-320/420AW Four weighers automatic vertical packing machine

Product name: JEV-320/420AW Four weighers automatic vertical packing machine

Combined parts

1. JEV series main machine

2. Four Heads Weigher

3.Platform

4.Material elevator

5.Finished product conveyor


Technical parameter

Model JEV-320AW JEV-420AW
Packaging material OPP/PP、OPP/CPP'' PT/PE、PE、KOP/CPP、PT/PE/x AL/PE etc. Any heat-sealable composite materials foil/film
Bag length 50-200mm(L) 300mm(L)
Bag width 50-150mm(W) 100-200mm(W)
Film width 320mm 420mm
Packing speed 8-60bags/min 5-60bags/min
Range of measurement 20-500ml 2500ml
Atmospheric pressure 0.65Mpa 0.65Mpa
Consumption 0.6m3/min 0.6m3/min
Voltage 220V 50/60HZ 220V 50/60HZ
Power 1.5Kw 3.0Kw
Dimensions L1067*W1026*H1288mm L1388*W116*H1536mm
Weight 300Kg 500Kg
